Traxxas 90386-4 Jato 4X4 VXL
š Traxxas Jato 4X4 VXL ā 1/8 Scale Brushless 4WD Buggy
The Traxxas Jato 4X4 VXL redefines 4-wheel-drive RC performance with 4s brushless power, high-tech telemetry, and the latest Traxxas heavy-duty components. A low-CG chassis, GTR shocks, and 2400 Kv VelineonĀ® motor combine to deliver explosive acceleration and rugged all-terrain controlāready to race right out of the box.
ā” Highlights
-
Clipless body system for quick, secure removal
-
Factory-installed Extreme Heavy Duty Upgrade Kit
-
Strengthened C-hubs, axle carriers & steering blocks
-
Maxx-duty 6 mm driveshafts, 17 mm hex hubs, aluminium wheel nuts
-
-
TQiā¢ 2.4 GHz Radio System with Traxxas Linkā¢ telemetry compatibility
-
VXL-4sā¢ Waterproof ESC ā 2sā4s LiPo compatible
-
VelineonĀ® 540XL 2400 Kv Brushless Motor
-
Aluminium T-bar chassis stiffener with modular composite tub
-
Shaft-driven 4WD with Torque-Biasing Center Drive
-
GTR oil-filled shocks with threaded collars
-
Response Pro S1-compound tires on 3ā³ dish wheels
š§ Power System
VelineonĀ® 540XL Brushless Motor
-
4-pole 2400 Kv design for brutal acceleration
-
5 mm shaft / 6.5 mm bullet connectors
-
Virtually maintenance-free and built for 4s LiPo power
VXL-4sā¢ Electronic Speed Control
-
2sā4s LiPo (7.4 V ā 16.8 V)
-
Selectable 6.0 V or 7.4 V BEC output
-
Real-time telemetry support via Traxxas Linkā¢
-
Sport / Race / Training modes with EZ-SetĀ® button
-
Waterproof housing with large heat sink and fan port
āļø Chassis & Suspension
-
Aluminium T-Bar Chassis Stiffener for strength and rigidity
-
Low-CG layout for maximum stability
-
Dual bellcrank steering with servo saver and 2075 digital servo
-
Reinforced shock towers with double-shear camber links
-
Heavy-duty suspension arms and HD hardware
-
Aluminium GTR Shocks with X-rings & large oil capacity
š§© Drivetrain & Transmission
-
Full-time shaft-driven 4WD with Torque-Biasing Center Drive
-
Sealed steel-gear front and rear differentials
-
Steel 32-pitch gears for maximum durability
-
Rust-resistant black-oxide hex hardware throughout
š Wheels & Tires
-
3ā³ dished buggy wheels with 17 mm hex hubs
-
Response Pro S1-compound tires with foam inserts for grip and control
š Specifications
| Specification | Details |
|---|---|
| Scale | 1/8 |
| Drive System | Shaft-driven 4WD with Torque-Biasing Center Drive |
| Skill Level | 2 |
| Length | 517 mm (20.4ā³) |
| Width | 305 mm (12ā³) |
| Height | 179 mm (7ā³) |
| Wheelbase | 320 mm (12.6ā³) |
| Weight | 2.54 kg (5.6 lb) |
| Gear Pitch | 32 Pitch |
| Overall Drive Ratio | 10.16 : 1 |
| Differentials | Hardened steel bevel, sealed, limited-slip |
| Shock Length (F/R) | 101 mm (XX-long) |
| Battery Compartment | 165 Ć 50 Ć 35 mm |
| Motor | VelineonĀ® 540XL 2400 Kv |
| ESC | Velineon VXL-4s Waterproof |
| Radio System | TQiā¢ 2.4 GHz High-Output |
| Servo | 2075 Digital Waterproof (125 oz-in) |
ā” Power Compatibility
Battery Types: 2sā4s LiPo / Traxxas High-Current Connectors
Charging: Compatible with Traxxas EZ-PeakĀ® and iDĀ® Chargers
